Float Ball For Water Tank
Description
Technical Parameters
The stainless steel float ball for water tanks offers excellent corrosion resistance, pollution resistance, and high temperature resistance due to its superior material properties. With its ability to withstand corrosive environments and extreme temperatures, this float ball ensures long-lasting performance and consistent quality. Additionally, it effectively handles various pollutants found in water and high-temperature conditions, guaranteeing a safe and reliable water supply. Moreover, this float ball is environmentally friendly and promotes cleanliness as it is free from any harmful substances. Its simple structure simplifies maintenance procedures, saving on costs by eliminating the need for additional tools and components. Versatile in its applications, this float ball is suitable for use in liquid and gas pipeline systems, including water supply, fire protection, chemical, and oil drilling equipment.
Features
1. This float ball for water tankThe principle behind its design is rooted in hydraulics. Its mechanism involves the elevation of a floating ball, which effectively seals off the valve port when excessive amounts of liquid or gas are present in the pipeline. As a result, it effectively regulates the flow.
The water level can be efficiently regulated and the water flow effectively controlled with the use of this highly sensitive float. This feature not only helps in conserving water resources but also ensures the smooth functioning of the system.
The 304 stainless steel floating ball boasts superior corrosion resistance compared to regular balls, making it last longer without sustaining damage. Because of this, costly maintenance is not necessary, saving time and money.
The product contains a silicone sealing ring with a hardness rating of 60. Can you create new content that conveys the same information by using the language model to generate entirely distinct language?float ball for water tankThis material has many desirable qualities, including resistance to oil, acid, and alkali, as well as the ability to withstand wear and fire. Additionally, it has a high tolerance for extreme temperatures, whether hot or cold. These properties make it an excellent choice for use in applications where leaks and other damage must be avoided.
Quick Details
Type: auto fill float valve Place of Origin: Zhejiang, China Brand Name: SINPO Application: General Temperature of Media: High Temperature, -10~100℃ Power: Manual | Port Size: 1 1/2 to 8 inch Body material: CF8(304) or CF8M(316) Standard: ANSI, JIS, GB, DIN Certificate: CE, RoHS, ISO9001, TUV Suitable Medium: Water, Oil, Steam, Liquid, etc |
Supply Ability
10000 Piece/Pieces per Month
Packaging Details
Our packaging process involves placing each product in a plastic bag before carefully packing them into internal fields and cartons. These cartons are then packed into sturdy plywood cases or pallets for added protection during transportation.
Port
Ningbo, Shanghai, etc
Lead Time
The majority of our items are currently available, with only a few items out of stock. If an item is not in stock, the estimated wait time is between 15 and 25 days.
Specification
Connection | Flanged end |
Material | Stainless Steel |
Pressure | 0 to 6 bar |
Medium Temperature | -10 to 100℃ |
Mediums | Water, oil, air, gas, and other mediums |
Materials:
No. | Part Name | Material | No. | Part Name | Material |
1 | Body | SS304,SS316 | 7 | Nut | SS304,SS316 |
2 | Lock nut | SS304,SS316 | 8 | Nut | SS304,SS316 |
3 | Flange | SS304,SS316 | 9 | Nut | SS304,SS316 |
4 | Plug | Silicone, NBR | 10 | Nut | SS304,SS316 |
5 | Piston | SS304,SS316 | 11 | Ball | SS304,SS316 |
6 | Stem | SS304,SS316 |
Dimensions:
Size | D1 | t | e | L1 | L2 | L4 | L5 | d | D | S |
1 1/2” | 140 | 13 | 18 | 35 | 54 | 120 | 450 | 21 | 21 | 220mm |
2” | 155 | 13 | 18 | 40 | 72 | 130 | 450 | 27 | 27 | 250mm |
2 1/2” | 175 | 15 | 18 | 42 | 80 | 150 | 540 | 37 | 37 | 300mm |
3” | 190 | 15 | 18 | 48 | 95 | 170 | 650 | 47 | 47 | 380mm |
4” | 210 | 17 | 18 | 55 | 110 | 195 | 650 | 60 | 60 | 380mm |
6” | 280 | 19 | 23 | 55 | 110 | 195 | 780 | 60 | 60 | 380mm |
8” | 330 | 19 | 23 | 55 | 110 | 195 | 780 | 60 | 60 | 380mm |
Note:Flange can be personalized in accordance to customers’ requirements.
Production Process
Our product manufacturing consists of 5 steps, particularly roughcast casting,processing with the aid of machine,assemble,pressure check and packing.
Packaging
1. Commonly package deal the merchandise with the aid of plastic bag and put it into carton,pallet or wood cases.
2.Others packaging techniques are customized.
Shipping
1. We may want to supply the items by using worldwide express, such as DHL, UPS, TNT, EMS, others.
2. You ought to additionally pick the transportation in accordance to your agenda and budget.
3. Or you may want to use your personal cargo agent.
FAQ
1.How long will you give me the reply?
A:we will contact you in 24 hours as soon as we can.
2.If products have some quality problem,how would you deal with?
A:We will responsible for all the quality problems.
3.Can you produce the products according to my own drawings?
A: Yes, we can produce the products according to your drawings that will be most satisfy you.
4.Which industries will be applied to your valves and fittings?
A:The oil & gas, coal mine, water conservancy, drilling, power station project, metallurgy and chemical industries etc.
5.What if I find a problem with the product?
A:Okay, we will solve it for you.
